Functional ink(ALSOLAR®)
Outline
ALSOLAR®is our Al paste trade mark for crystalline silicon solar cells contact fabrication using screen-Printing technology. The advanced technology of paste manufacturing is used to mix our special Al powder, organic binders and solvent with special glass frits developed to realize high solar cell efficiency.
Alsolar pastes are developed to meet the customers high efficiency solar cells requirement and insure excellent reliability and performance. Our high quality pastes :
For p-type Si Solar Cells
◆ALSOLAR® PERC Paste, TLCO Series
◆ALSOLAR® Bifacial PERC Paste, TB Series
For n-type Si Solar Cells
◆ALSOLAR® PERT-BJ Paste, TDN Series
◆ALSOLAR® Bifacial PERT Paste, TBN Series
◆ALSOLAR® Passivated Contact (TopCon, MonoPoly, Polo Cells) TTC series
◆ALSOLAR® Fire-Through Paste, TFT Series
Characteristics of fired cells using ALSOLAR®
ALSOLAR® delivers high conversion efficiency specially in PERC solar cells with our special Void-Free paste, efficiency can reach +0.2% due to the higher quality of local BSF that increases the Voc by up to 5mV
| Fired cell characteristics (Representative values) | |||||||
|---|---|---|---|---|---|---|---|
| Conversion efficiency* | Warping* | TC* | DH1000* | Hot Water* | Peel strength* | ||
| mc-Si | CZ | ||||||
| ～ + 0.2% | ～ + 0.2% | < 1.5 mm | < 5% | < 5% | > 20min@ 75 ℃ |
> 20N | |
* In House Measurement
